Access control reader
FingerTec i-Kadex in the UAE
The FingerTec i-Kadex is a access control reader from FingerTec, using fingerprint, rfid card and pin or password as the credential. It stores 30,000 users on the device itself. It connects over Wiegand. Environmental rating: IP65, so it can go where the indoor-only Kadex master cannot. It runs with Managed through the master terminal under Ingress / TCMS V3.
- Manufacturer
- FingerTec
- Category
- Access control reader
- Credentials
- Fingerprint · RFID card · PIN or password
- Capacity
- 30,000 users
- Connectivity
- Wiegand
Where this unit fits
- Gates, compounds and exposed entrances that see full UAE summer sun and dust
- Large headcounts and shift changes that must clear without a queue
- Adding a second read point so one door records both entry and exit
- Slotting into an access control panel you already own
- Slim mullion-style exit reader
- The cheapest way to add a second reader to a Kadex door
- IP65 rated unlike the indoor-only master
Full specification
Taken from the manufacturer's own datasheet, with the source linked.
| Brand / Manufacturer | FingerTec |
|---|---|
| NAME CORRECTION | The correct product name is i-Kadex, not i-Kedax. |
| Device type | RFID card SLAVE / exit reader for the Kadex series |
| Verification methods | RFID card only. No keypad, no PIN, no fingerprint |
| Capacity | None of its own. It is a card capturing station. All 30,000 cards and 50,000 logs are held in the master |
| Display | None, LED indicator only |
| Communication | Wiegand 26-bit output to the master terminal |
| Access control | Provides the second (exit) read point so the master handles IN and OUT. It can also be attached to an Ingressus controller or a third-party controller, in which case that controller becomes the master |
| Power supply | Supplied and managed by the master terminal or controller |
| Operating temp. | -10 to 70 C, humidity 20-80% |
| Dimensions | 55 x 15 x 100 mm |
| Protection rating | IP65, so it can go where the indoor-only Kadex master cannot |
| Software | Managed through the master terminal under Ingress / TCMS V3 |
The correct product name is i-Kadex, not i-Kedax.
Where this data comes from
Every specification here is checked against the manufacturer's own document before it goes live.
Common questions
- How many employees does the FingerTec i-Kadex hold?
- The FingerTec i-Kadex stores up to 30,000 enrolled records on the device. We check your headcount and peak-minute traffic before recommending it.
- How does the FingerTec i-Kadex connect?
- It supports Wiegand. In UAE installations we normally run it on wired Ethernet, with Wi-Fi kept as the fallback where cabling is impractical.
- Can the FingerTec i-Kadex be installed outdoors in the UAE?
- The manufacturer rates it IP65, so it can go where the indoor-only Kadex master cannot, with an operating range of -10 to 70 C, humidity 20-80%. We still specify a shade hood on elevations that take direct midday sun, which extends screen and sensor life.
- What software runs the FingerTec i-Kadex?
- Managed through the master terminal under Ingress / TCMS V3. We connect the attendance data through to payroll and produce a WPS-ready export, so the punches become a payable file rather than a report someone has to retype.
- Do you install and support the FingerTec i-Kadex across the UAE?
- Yes. We supply, install, configure, train your team and support it across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain. Call +971 54 707 9900 for a fixed written quote.
